TQ35 IRC

Print to PDF
  • Reference ID 343
  • Builder NMD(New builds)
  • Model TX35IRC
  • Designer NIVELT MURATET
  • Year 2019
  • L.O.A. (mtr) 10.32
  • Draft (mtr) 1.95
  • Displacement (Kg) 3300
  • Material Vinylester
  • Send to email

Yacht description

Following a collaboration on a highly successful offshore racing yacht NMD43 “Albator”, Nivelt Muratet Design and Oceantec have joined forces again to provide the ocean-going IRC racing yacht with true planing potential.

The TQ35 is  designed for fast, predominantely offshore IRC racing – shorthanded or fully crewed.

The TQ35 incorporates a powerful, highly refined hull form, a practical living space, rugged hightech composite structure, and simple, reliable systems.

Price indicated starts from €130.000 ex VAT, ex Ocean tec-yard, Slovenia
Excluding Sails, Electronics, safety-Equipment and possible options

General

Water Ballast (per side): 300L
Mainsail Area 36 m²
Headsail Area 29 m²
Gennaker Area 115 m²
CE Category A
IRC rating TTC (“Transquadra” – no water ballast) app. 1.045
IRC rating TTC (full crew + water ballasts) app. 1.060
Yacht Designer Nivelt Muratet Design
Builder Ocean tec

Construction

  • 5-axis CNC machined hull and deck tooling.
  • Vinylester infused SAN foam core sandwich and E-glass reinforcements.
  • Bulkheads and inner structure vinylester infused SAN foam core sandwich with unidirectional reinforcements.
  • White gel coat finish outside, 2-part PU paint sprayed inside.
  • Flush mounted seacocks.

Keel

  • 1,95 draft T-keel.
  • Cast SG iron fin.
  • Antimonial lead bulb.
  • Keel assembly faired to a racing finish.

Rudder and steering:

  • Twin spade rudders with E-glass foam sandwich blades and stainless steel stocks.
  • Self aligning rudder bearings.
  • Tiller arms with connecting bar.
  • Fixing positions for 2 x autopilot rams.
  • Single tiller steering system Jefa or similar.

Rigging

  • Keel-stepped standard Aluminum mast, boom and spreaders.
  • Dyform standing rigging.
  • 1 x Mainsail halyard (2:1).; 1 x Jib halyard.; 1 x Staysail halyard.; 1 x Fractional halyard; 2 x Masthead halyards (1 x 1:1; 1 x 2:1).
  • Removable inner forestay.

Accommodations

  • Forward watertight bulkhead.
  • Separate sails storage compartment
  • Enclosed head compartment, marine toilet with holding tank, sink with hand operated faucet.
  • Watertight door to sails storage compartment
  • Saloon area with generous settee seating and fixed table incorporating storage and sink with handoperated faucet. Saloon setees backrests convertible to pipe cots
  • Galley with cooker to port with overhead lockers and additional seating.
  • Forward facing navigation station with confortable seating to starboard. Overhead electrical panel and storage.
  • Aft cabins with double berths and pipe cots.
  • All interior units are moulded from foam cored E-glass sandwich panels with a polished gelcoat finish.
  • Berth mattresses and saloon seating cushions
  • Cabin sole boards from foam cored E-glass sandwich panels.
  • Flexible freshwater tank with deck filler.
  • Marine toilettte
  • Holding tank provided for toilet.

Deck and Cockpit

  • High density foam inserts, additional reinforcements &/or E-plates in way of all high load fittings.
  • Harken winch and hardware package
  • Spinlock clutches.
  • Pit 2 x Harken Performa winch (TBC).
  • Primary 2 x Harken Performa winch (TBC).
  • Main sheet / Utility 2 x Harken Performa winch (TBC).
  • Harken Mainsheet system and traveller.
  • Floating ring / transverse track jib lead (TBC).
  • Carbon fibre bow sprit.
  • 316 stainless steel headstay chainplate.
  • Composite chainplates for V1, D1
  • Ropeye fittings for backstay and inner forestay.
  • Round foredeck hatch and 2 portlights for aft cabins
  • Composite watertight companionway door.
  • Integrated bulwark / toe-rail
  • Pushpit, pulpit and stanchions seated on composite spigots with lock fastening.
  • Bow fairlead / strong point for towing.
  • Clipping points for jackstays.

Electrics

  • Engine start battery 65Ah.
  • 2 x Consumer batteries 90Ah.
  • 12V electrical panel with switches located at Navigation station.
  • Battery monitoring display.
  • LED navigation lights at masthead, bow and stern.
  • LED interior lightning.
  • Electrical equipment accessible for maintenance, repair or removal.
  • Electrical equipment and cabling of a type proven satisfactory for marine use.

Engine

  • 22hp marine diesel engine with saildrive unit (Yanmar or similar).
  • Standard engine alternator.
  • 2-blade Flexofold race propeller.
  • Ventilated engine and machinery space with sound & vibration proofing.
  • Engine and machinery space accessed via lifting companionway steps.
  • Exhaust system running to transom.
  • Engine control panel located by starboard helm station.
  • Single lever Morse control by starboard helm station.
  • 60L fuel tank with deck filler.

Safety

  • 2 x manual bilge pumps.
  • 2 x Automatic Electrical bilge pumps
